AWR26
WMTCNC
8459310000
| Quantity: | |
|---|---|
Product Description
Features:
The Diamond Cut Alloy Wheel Lathe is ushering in a new era for diamond cut alloy wheels. This CNC alloy wheel lathe is characterized by its innovative purpose-built design. Built from the ground up both mechanically and electrically the system offers an easy-to-use touchscreen interface coupled with the latest state-of-the-art real-time control software driving the latest in motion control digital drive technology.
| Item | AWR26 | |
| Capacities | Max.Swing diameter over bed | 660(26” ) |
| Max.swing diameter over gap | 760 | |
| Max. Size of alloy wheel | 660 | |
| (26“) | ||
| Max.turning length | 650 | |
| Width of the rail | 360 | |
| Travel | Axis travel | X : 350; Z : 500 |
| Spindle | Spindle speed | 40-1800 |
| Spindle taper | 6# | |
| Spindle hole | 52 | |
| Turret | Tool number | 4 |
| Tool shank size | 25×25 | |
| Feeds | Rapid traverse of ×axis | 3000 |
| Rapid traverse of Z axis | 6000 | |
| Cutting feed | 0.005-100 | |
| Motor | Main motor power | 5.5 |
| X and Z axis motor | Servo motor | |
| Others | Overall dimension (L×W×H ) | 2100x1700x1950 |
| Weight | 2300 | |
