D250V
WMTCNC
| Quantity: | |
|---|---|
Product Description
Features:
1) Precision ground and hardened bed ways.
2) The spindle is supported with precision roller bearings.
3) Headstock gears are made of high quality steel, ground and hardened.
4) Easy operating speed change levers.
5) Easy operating gear box has various feeds and thread cutting function.
Specification:
| Specification | D250V |
| Swing over bed | Φ250mm |
| Swing over cross slide | Φ140mm |
| Admits between centers | 500mm |
| Center height | 125mm |
| Width of bed | 135mm |
| Spindle bore | Φ26mm |
| Taper of spindle bore | MT4 |
| Range of spindle speed | 50-2500rpm |
| Compound rest travel | 75mm |
| Cross slide travel | 100mm |
| Lead screw thread | Tr20X3-L |
| Max.Section of tool（W×H） | 12X12mm |
| Threads metric pitches | 0.2-3.5mm |
| Threads imperial pitches | 8-56TPI |
| Quill diameter | Φ30mm |
| Quill travel | 60mm |
| Quill taper | MT2 |
| Main motor power | 1.1KW |
| Dimensions(L*W*H) | 1100×500×500mm |
| Net weight/Gross weight | 137/150kgs |
| Shipping dimensions(L*W*H) | 1200×560×580mm |
