Features:
1.The Metal surface grinding machine table in longitudinal movement driven by the vane pump, which is stability and low noise. The temperature of oil pool is low and the precision is fit for National Standard (GB/T4022-1983).
2.It can be carried out trough and flange lateral grinding.
3.Grinding head has rapid movements mechanism invertical movement, but also manually feed.
4.Grinding head vertical move can be adopted with power rapid movement or hand micro feed.
5.Grinding head motor and pump motors are high-grade motor, electrical carry out the national safety standards
6.Metal surface grinding machine have a position for installing digital readou
Specifications | M7163 |
Worktable size | 630x1250/1600/2200/3000/4500 mm |
Max. processing dimension width | 630mm |
Max. processing dimension length | 1250/1600/2200/3000/4500 mm |
Max. processing dimension height | 500 mm |
Max.distance between spindle center to worktabe surface | 700 mm |
Lingitudinal moving speed of worktable | 3-27mm/min |
T slot number*W | 3*22 mm |
Consecutive feed speed | 0.5-4.5m/min |
Intermittent feed speed | 3-30mm/t |
Rapid speed | 400mm/min |
Hand wheel feed | 0.005mm/gra |
Motor power | 7.5kw |
Motor speed | 1440rpm |
Total power | 13.75/15.75kw |
Max.loading capacity of worktable with chuck | 1010/1290/1780/2430/3650 kg |
Wheel size (OD*W*ID) | 400*40*230 mm |
Machine size lenght | 3300/5320/5750/7880/12170 mm |
Machine size width | 1900 mm |
Machine size height | 2420 mm |
