Features:
The machine can cut all kinds of inside and outside plane of large and medium parts.
The sliding reciprocating motion of profile surface and keyway can be adjusted in work without stopping.
The slide bed, work table and oil pump are driven by separate electric motors.
The cutting speed can be step-less adjusted.
Machine has various safety devices like electromagnetic automatic knife lifting .
The tool holder is used for external cutting,and the tool bar is used for interpolation and keyway.
Specification | BC50100 |
Maximum cutting length(interpolated inner hole 850mm) | 1000mm |
Cutting stroke speed | 425m/min |
Return travel speed | 7-25m/min |
Maximum weight for plug gable work | 4000kg |
Main drive motor power | 37kw |
Allow maximum cutting force(when the stroke speed is 16m-20m) | 24500N |
Table diameter | 1250mm |
Maximum movement of the workbench | 1200/1100mm |
Distance from the tool support surface to the front wall of the bed | 1120mm |
Feed range | 0. 2-5mm/double stroke |
Landscape | 0. 2-5mm/double stroke |
Circumference(on the circumference of 9700) | 0. 4-10mm/double stroke |
Distance from work surface to the lower end of the carriage | 1140mm |
Workbench fast moving longitudinal and horizontal | 500mm/min |
Machine dimensions (length X width x height | 400×2830×570mm |
Total machine weight(including electrical equipment | 22T |
