Product Description
Main Features:
This lathe is a special purpose heavy duty horizontal face lathe and it is suitable for turning the internal/external cylindrical surface, conical surface, end face and so on with large-diameter, medium length for all kinds of workpieces.
| Specification | Model | CDS6266-1500 | |||
| Capaci ties | Max. swing over bed | 660mm | |||
| Max. swing over slide | 440mm | ||||
| Workpiece cutting length | 1500mm | ||||
| Max. swing over gap | 920mm | ||||
| Bed width | 395mm | ||||
| Head stock | Spindle hole | φ103mm | |||
| Spindle nose | D8 | ||||
| Spindle taper | 1:20 | ||||
| Spindle speeds | 26-1700(16STEPS） | ||||
| Feeds | Metric threads rang | 0.5-80（38） | |||
| Inch threads rang | 7/16-80（42） | ||||
| Module threads rang | 0.5-40（31） | ||||
| Pitch threads rang | 7/8-160（42） | ||||
| Longitudinal feed rang | 0.044-1.48 | ||||
| Cross feeds rang | 0.022-0.74 | ||||
| Carriage | Cross slide travel | 350mm | |||
| compound rest travel | 150mm | ||||
| Cross-section size of tool shank | 25 | ||||
| Tail stock | Taper of tailstock sleeve | MT5 | |||
| Diameter of tailstock sleeve | φ75 | ||||
| Travel of tailstock sleeve | 150mm | ||||
| Motor | Main motor power | 7.5kw | |||
| Cooling bump motor | 0.125kw | ||||
| Rapid motor | 0.275kw | ||||
