CS6266C- 26''x79'' Industrial Grade Big Bore High Precision Engine Lathe

  • CS6266C
  • WMT
  • 84581900
Quantity:

Product Description

Features:

  • Perform internal and external turning, taper turning, end facing, and other rotary parts turning;

  • Threading Inch, Metric, Module and D.P.;

  • Perform drilling, boring and groove broaching;

  • Respectively with through-hole spindle bore, that can hold bar stocks in larger diameters;

  • Both Inch and Metric system are used on these series lathes, it's easy for people from different measuring systems countries;

CS6266C


Specification for lathe machine CS6266C

Specification
CS6250C
CS6266C
CQ6280C
Max. swing over bed
Φ500mm
Φ660mm
Φ800mm
Max. swing in gap
Φ710mm
Φ870mm
Φ1000mm
Max. swing over slide
Φ300mm
Φ420mm
Φ560mm
Max. workpiece length
1000/1500mm / 2000/3000mm
2000/3000mm
Spindle bore
Φ105mm
Type of spindle
ISO 702/II NO.8 com-lock type
Spindle speed
12 steps:36-1600rpm
12 steps:30-1400rpm
Spindle motor
7.5kw
Diameter of quill
Φ90mm
Max. travel of quill
150mm
Taper of quill
MT5
Tool O.D. size
25×25mm
Max. X travel
145mm
Max. Z travel
320mm
310mm
320mm
X feed range
65 kinds 0.063-2.52mm/r
Z feed range
65 kinds 0.027-1.07mm/r
Metric threads
22 kinds 1-14mm
Inch threads
25 kinds 28-2t.p.i
Module threads
18 kinds 0.5-7πmm
Diametric pitch
24 kinds 56-4t.p.i.π
Cooling pump
60w
Length
2632/3132mm/3632/4632mm
3365/4365mm
Width
975mm
1340mm
Height
1270mm
1450mm
1490mm
N.W
2100/2300kgs/2500/2900kgs
3000/3200kgs
G.W
2200/2400kgs/2600/3000kgs
Machine accessories

Standard accessories:

1) 3-jaw chuck       2) 4-jaw chuck
3) face plate          4) steady rest
5) follow rest         6) face plate
7) work lamp         8) coolant system
9) splash guard     10) foot brake
11) dead centers   12) tool box tools

Optional accessories:

1) 2- axis Sino DRO
2) 3-axis Sino DRO
3) taper attachment
4) Quick change toolpost
5) live center

1) Optional accessories:

quick change toolpost

2) Optional accessories:

Digital read out

3) Optional accessories:

Taper turning attachment
