DIY1028 Gear Head Metal Lathe

  • DIY1018/DIY1028
  • WMT
Availability:
Quantity:

Product Description

DIY1028

Specification DIY1028
Distance between centers 450/ 700mm(17-3/4"/27-1/2")
Swing over bed 250mm(10")
Swing over cross slide 115mm(4-1/2")
Taper of spindle bore MT4
Spindle bore 27mm(1")
Step of spindle speeds 6 steps
Range of spindle speeds 115-1620rpm
Range of inch threads 8-56T.P.I
Range of metric threads 0.2 -3.5mm /r
Travel of cross slide 140mm
Taper of tailstock quill MT3
Main Motor 750W
Packing size 1260/1510×570×580mm
Net/gross  weight 151kg / 171kg

Features:

1) Widely useful

2) Operation very easy

3) Cost-efficient
