XK7124
WMTCNC
| Quantity: | |
|---|---|
Product Description
Features:
1. XK7124 Small size vertical CNC milling machine with CE certificate.
2. BT30 spindle.
3. Function: drilling , tapping, chamfering, bearing, milling face thread, handle and tower.
4. Aesthetic and elegant modeling.
5. High efficiency for automatic knife changing.
6. The spindle frame is used in the lathe pedestal to increase its stability and stiffness.
Specification:
| Specification | XK7124 |
| worktable | |
| Worktable size(LxW) | 800x240mm |
| T-slot (N×W×D) | 3-16X60mm |
| Travel | |
| X axis travel | 425/245/530mm |
| Machining range | |
| Spindle center to column distance | N/A |
| Distance from spindle nose to worktable surface | 105-635mm |
| Spindle | |
| Spindle taper | BT30 |
| Main motor power | 3.7kw |
| Coolant system | N/A |
| Change tool way | Pnumetic |
| Rapid feed speed(X/Y/Z) | 10/10/10 m/min |
| Max.spindle speed | 6000rpm |
| Feed | |
| AC servo motor torque (X/Y/Z) | N/A |
| Ball screw (diameter+lead） | |
| XY Linear guideway | N/A |
| Z linear guideway | N/A |
| X axis ball leadscrew | 2506 |
| YZ axis ball leadscrew | 2506 |
| Tool magazine | |
| ATC Type | Umbrella type |
| Capacity of ATC | 12T |
| Air compressor pressure | N/A |
| Lubricating pump capacity | 1L |
| Working light | 10w |
| Cooling pump | 40w |
| Controller system | After18i//GSK980MDc/Siemens 808Da |
| Size | |
| Machine size(LxWxH) | 1540（1730）x1300x1960（2060）mm(including ATC） |
| Machine weight | 600kg/750kg |
