Features:
1.The Metal surface grinding machine table in longitudinal movement driven by the vane pump, which is stability and low noise. The temperature of oil pool is low and the precision is fit for National Standard (GB/T4022-1983).
2.It can be carried out trough and flange lateral grinding.
3.Grinding head has rapid movements mechanism invertical movement, but also manually feed.
4.Grinding head vertical move can be adopted with power rapid movement or hand micro feed.
5.Grinding head motor and pump motors are high-grade motor, electrical carry out the national safety standards
6.Metal surface grinding machine have a position for installing digital readout.
Specification | MA618 | MA820 | MA1022 |
Table size | 460x180mm | 450x200mm | 520x250mm |
Wheel size | 180x13x31.75mm | 200x20x31.75mm | 200x20x31.75mm |
Spindle speed | 2800r/min | 2800r/min | 2800r/min |
Spindle motor | 1.1kw | 1.5kw | 1.5kw |
Surface roughness | Ra0.32μm | Ra0.32μm | Ra0.32μm |
Cooling motor | 0.04kw | 0.04kw | 0.04kw |
Net weight | 750kg | 800kg | 880kg |
Gross weight | 800kg | 890kg | 980kg |
Demensions | 1240x1080x1900mm | 1460x1160x1960mm | 1400x1200x1980mm |
