Q1353
WMTCNC
| Quantity: | |
|---|---|
Product Description
Main Features:
1 Large spindle aperture with high passability and stable workpiece clamping with double chucks;
2 High quality and high strength cast iron casting overall bed with good rigidity and high precision;
3 The surface of the guide rail is quenched by super audio treatment, with great hardness and long service life;
4 Equipped with a taper bar device, convenient for cutting taper thread.
Specification
| Specification | Q1353 |
| Capacity | |
| Chuck size | 4-jaw eletric(1000) |
| Max. swing dia over bed | 1250mm |
| Max. swing dia over slide | 860mm |
| Max. length of workpiece | 1500mm |
| Width of bed | 755mm |
| Spindle | |
| Spindle bore | 540mm |
| Spindle motor power | 22kw |
| Spindle speed | VF 2.steps(20-220)r/min |
| Axis | |
| Z axis feed grade/range | 32/0.1-1.5mm/r |
| X axis feed grade/range | 32/0.05-0.75 |
| carriage rapid traverse speed | 3740mm/min |
| corss slide rapid traverse speed | 1870mm/min |
| Metric thread grade /range | 22/1-15mm |
| Inch thread grade /range | 22/28-2T.P.I |
| Traverse of corss slide | 620mm |
| Max.Traverse of turret | 300mm |
| Tailstock | |
| Tailstock quill diameter | 160mm |
| Tailstock quill travel | 300mm |
| Tailstock quill taper | MT6 |
| Machine Dimensions | |
| Overall dimensions(LxWxH) | 5000×2420×2070mm |
| Machine weight | 16t |
