Features:
1. The machine is a high-speed, high-precision, high-reliability inclined bed numerical control machine tool, the spindle is a unit structure, servo main motor, can achieve higher rotational speed, workpiece clamping selection of hydraulic chuck, higher accuracy, more labor-saving.
2. Fully enclosed protection, no leakage of oil and water, both environmentally friendly and beautiful.
Specification:
Specification | XK7136C |
Worktable size(LxW) | 1250x360mm |
T-slot (NxWx D) | 3/18/80mm |
X axis travel | 900mm |
Y axis travel | 350mm |
Z axis travel | 500mm |
Distance from spindle nose to worktable surface | 100-600mm |
Distance from spindle center to column | 460mm |
Rapid feed speed(X/Y/Z) | 10/10/8m/min |
Spindle taper | BT40 |
Spindle speed range | 8000rpm |
Main motor power | 5.5kw |
AC servo motor torque(X/Y/Z) | 7.7/7.7/7.7N.m |
Over size(LxWxH) | 2200x1850x2350mm |
Net weight | 2400kgs |
